Introduction: Huashengming double-roll crushers demonstrate exceptional performance in aggregate crushing, with their effectiveness primarily manifested in precise particle size control, low ...

Huashengming double-roll crushers demonstrate exceptional performance in aggregate crushing, with their effectiveness primarily manifested in precise particle size control, low energy consumption, superior aggregate shape, and broad applicability. Huashengming’s 100 tph stone crusher

1. Core Model and Technical Specifications

2PGT750×500 Model

Capacity: 50–100 tonnes/hour (high-specification version accommodates 100-tonne requirements)
Output particle size: 1–3mm (hydraulically adjustable)
Motor power: 22kW × 2 (dual-motor drive)
Suitable materials: Medium-hard materials such as limestone, river pebbles, coal gangue

Model 1210 Double-roll Crusher

Capacity: Over 100 tonnes/hour
Features: Intelligent control system, wear-resistant roll liners (3+ year lifespan), suitable for both dry and wet materials
Output size: Adjustable 1-5mm, low needle/flake content

SCF Series Two-Stage Crusher (Wet Material Specialised)

Capacity: 100-120 tonnes/hour
Advantages: Screenless design prevents blockages when processing high-moisture materials

2. Price Range

Basic Model: ¥180,000–200,000 (e.g., 2PGT750×500, includes standard configuration)
High-Spec Model: ¥250,000–400,000 (e.g., 1210 model, includes intelligent control system and wear-resistant alloy roll liners)
Custom Model: Quotation required based on material characteristics (e.g., hard rock, slag) and additional functions (dust extraction, automation)

3. Core Advantages

High efficiency and wear resistance: Roller linings utilise high-manganese steel or special alloys, with a service life of up to 3 years
Intelligent adjustment: Hydraulic system precisely controls discharge particle size, enabling automated operation
High adaptability: Suitable for both dry and wet materials, capable of processing hard rock (granite, basalt) and slag
Energy-efficient and environmentally friendly: Energy consumption reduced by 30% compared to traditional equipment, with noise and dust control meeting regulatory standards

4. Model Selection Recommendations

Conventional aggregates (limestone, river pebbles): Opt for 2PGT750×500 or 1210 models for superior cost-effectiveness
Hard rock/slag: Prioritise 1210 model or SCF double-stage crushers for enhanced wear resistance
Wet/adhesive materials: Double-stage screenless models offer superior clogging prevention
